New energy commercial vehicle
| Model | WH6101GBEV | |
| Main?size?parameters | ||
| Dimension | 10480×2530×2950,3100 | |
| Wheelbase（mm） | 5350 | |
| Tread（mm） | Front?wheel | 2060，?2040 |
| Rear?wheel | 1860，?1870 | |
| Min.Ground?Clearance（Loaded）（mm） | 140 | |
| Front?Suspension（mm） | 2480 | |
| Rear?Suspension（mm） | 2650 | |
| Approach?Angle（°） | 8 | |
| Departure?Angle（°） | 7 | |
| Rated?passenger | 80/?24-40 | |
| Curb?Weight（kg） | 10900 | |
| Max.Weight（kg） | 16900 | |
| Chassis | ||
| Tire | 275/70R22.5 | |
| Axle | Integral?F/R?axle | |
| Suspension?Form | Leaf?Spring、Air?Suspension | |
| Main?performance?parameters | ||
| Min.Turning?Diameter（m） | 11 | |
| Max.speed（km/h） | 69 | |
| Recharge?mileage（km） | 235 | |
| Battery?Type | Lithium?Manganese?Battery | |
| Motor?rated?voltage（V） | 576 | |
| Battery?Management?System | Intelligent?centralized | |
| Total?Capacity（kWh） | 138.2 | |
| Rated?Power（kW） | 100 | |
| Motor?peak?power（kW） | 250 | |
| Motor?rated?torque（Nm） | 830 | |
| Motor?peak?torque（Nm） | 2800 | |
